Photo courtesy xa-blt.com (authorized for 3DWK use). 3DWK example page — brand remains 3DWK; not a BLT storefront listing.
ProcessMetal powder-bed fusionمثال · قيد التأكيد / 「示例、待确认」
MaterialAl or Ti alloyمثال · قيد التأكيد / 「示例、待确认」
StructureTopology-style webs, tube mountsمثال · قيد التأكيد / 「示例、待确认」
InterfacesBolt bosses / tube seatsمثال · قيد التأكيد / 「示例、待确认」
| Item | Typical value | Note |
|---|---|---|
| Post | Support removal, optional CNC datums | مثال · قيد التأكيد / 「示例、待确认」 |
Design intent
This example shows a lightweight frame where material follows load paths and openings stay clear for packaging.
- Keep fastener faces accessible for support removal
- Confirm tube or pin seats as machined datums when fit matters
- Do not invent flight loads or certification marks on this page
Manufacturing notes
Organic webs need printable thickness and inspectable sections. Mark which faces are sealed or bonded.
All dimensions and alloys on this page are examples to be confirmed — not a quotation.
What to put on the RFQ
- Preferred alloy family
- Which faces are critical for flatness or bore size
- Any NDT expectations (state them; we do not invent certifications)
مثال · قيد التأكيد / 「示例、待确认」
Next step
هل لديك دور مشابه ؟
رفع CAD والرسومات. يقوم المهندس بمراجعة المواد والتفاوتات والتشطيب قبل التسعير.
