Photo courtesy xa-blt.com (authorized for 3DWK use). 3DWK example page — brand remains 3DWK; not a BLT storefront listing.
ProcessMetal AMمثال · قيد التأكيد
MaterialNi superalloy (example)مثال · قيد التأكيد
JacketLattice over solid linerمثال · قيد التأكيد
BoreMay need flow-face finishمثال · قيد التأكيد
Lattice jacket cautions
Lattice around a flow liner can save mass but traps powder if cells are closed. Design escape holes and show them on the drawing.
- Transition lattice struts gradually into solid walls
- Keep the flow bore free of support scars if fluid performance matters
No pressure or temperature ratings are claimed on this example page.
مثال · قيد التأكيد
Next step
هل لديك دور مشابه ؟
رفع CAD والرسومات. يقوم المهندس بمراجعة المواد والتفاوتات والتشطيب قبل التسعير.
